Bentone BF1 - Pump Instructions; SUNTEC AS Pump Operation and Data

30
Bentone BF1
General
6. Instructions Pump
6.1 SUNTEC AS
Technical data AS47CK
One or two-pipe system.
Viscosity range: 1-12 mm
2
/s
Pressure range: 7-14 bar
Rated voltage of coil: 220/240V 50/60 Hz
Oil temperature: max 60°C
Components
1. Suction line G 1/4”
2. Return line G 1/4”and internal by-
pass plug
3. Nozzle outlet G 1/8”
4. Pressure gauge port G 1/8”
5. Vacuum gauge port G 1/8”
6. Pressure adjustment






165 105 20
