Bentone BF1
General
ø63
ø67
ø16
7,0–8,0
1,6–2,0
(-0,1)+0,5
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
10 15 20 25 30 35 40 45 50 55 60
Burner output, kW
Boiler overpressure, mbar
0,0
2,0
4,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
15 20 25 30 35 40 45 50 55
Burner output, kW
Scale
Air settings
Nozzle assembly
!
Scale value applies to 0 mbar furnace pressure.
2.1 Model BF1 FU/FUV 63-16
2.1.1 Burner output/ Basic settings
1,3 - 4,6 kg/h
15 - 55 kW
Length of blast tube
Protrusion from flange,
measurement B
Flange
1 2
102 85 69
132 115 99
