Bentone BG650 - Technical Data; Programme Sequence; Leakage Control

54
172 205 67 07-01
LEAKAGE CONTROL
Program sequence schedule
Controller
Motor pump
Solenoid valve
Differential pressure sensor
Release signal
Controller
Motor pump
Solenoid valve
Differential pressure sensor
Release signal
Controller
Motor pump
Solenoid valve
Differential pressure sensor
Release signal
Electrical connection VPS 504 Series 02
The VPS 504 is connected in series between the temperature regulator
and the control box via a 7-pole plug connector.
See the Bentone wiring diagram.
2(2)
untight
tight
Plug
Outlet
Lock-out Operation
Operating voltage
~(AC) 230V 50Hz
(S)
VPS 504 "TIGHT" TEST=41
VPS 504 "TIGHT" TEST =0,31
VPS 504 "NOT TIGHT"
