Bentone MVD 210 - Function LME

15 Bentone
3.2.1 Component list
3.3 Function LME...
1. Operating switch ON-Thermostat ON-Gas pressure switch ON
A check that the air pressure switch does not indicate fan pressure is
carried out.
2. Burner motor starts
A check that the air pressure switch indicates sucient fan pressure is
carried out.
3. The ignition spark is created
4. The gas solenoid valve is open
The gas is ignited. The ionisation electrode now indicates a ame.
5. The safety time expires
The ignition spark ceases. The safety period ceases. If the spark is missing
or it disappears after this time limit, the gas burner control is blocked.
6. Operating position
The burner is in operating position and can now change over to full load
if the operating switch and the thermostat for full load are in positon ON.
The burner can alternate between full and low load depending on set
temperature.
7. Stop
The operation of the burner can now be stopped with the control switch or
thermostat.
If the gas burner control is blocked
Red light in the gas burner control is lit. The burner is restarted by pushing
the reset button.
3.3.1 Technical data
!
Mains connection and fuse
in accordance with local
regulations.
A1 Gas burner control
A3 Valve, leak tester VPS504
B1 Ionization electrode
U2 UV-detector QRC (LME23...)
F1 Operating fuse
H1 Lamp, low capacity
M1 Motor
M2 Damper Motor STM6SF-L
P1 Time meter, total operating time
P2 Time meter, high capacity,
total operating time
S3 Control thermostat
S4 Temperature limiter
S6 Control thermostat, stage 2
S7 Main switch
S8 Air pressure switch
S9 Gas pressure switch
T1 Ignition transformer
Y1 Gas solenoid valve 1
Y2 Gas solenoid valve 2
Y1S Safety solenoid valve
X3 Plug-in contact, burner
X4 Plug-in contact, boiler
X5 Plug-in contact, stage 2, burner
X6 Plug-in contact, stage 2, boiler
LME23.331C2
3 s
30 s
2.5 s
< 3 s
< 1 s
< 1 s
5 µA
20 µA
160303-324
Preiginition time
Prepurge time
Postignition time
Safety lockout time
Reset time after lockout
Reaction time on  ame failure
Min. ionisation current at  ame
Max. ionisation current
