36
Bentone BFG 1
172 625 15-2
!
When servicing/replacing components which aect the
combustion, gas side leakage analysis and check should be
performed on the system.
11.3 Combustion device
1. Disconnect the main power and shut off the fuel supply.
2. Remove the gas pipe after ensuring that the gas is turned off.
3. Remove the burner from the burner ange. Pull out the burner.
Disconnect the blast tube and remove it.
4. If necessary, clean the brake plate and nozzle.
5. Check the ignition electrode and ionisation electrode. Replace if
necessary. (Refer to Technical data for setting of electrodes)
6. Install on the blast tube and fasten the burner on the burner ange.
7. Install the gas pipe.
8. Check the gas pipe for leakage.
9. Switch on the main power and open the fuel supply.
10. Start burner and check/adjust combustion.
!
Before obtaining access to electrical and fuel line components
all supply circuits must be disconnected.
