3.4 Control program at faults; fault mode
indicator LME ....
3.4.1 Colour codes
3.4.2 Diagnosing alarm causes
After alarm disconnection, the red alarm signal light is lit continuously.
The diagnosing of the alarm cause can be read according to the following
sequence:
3.4.3 Limiting of starting repetitions
LME 11... has a function with start repetition if the ame is not created at start
or disappears during operation.. LME 11... allows max. three repetitions during
continuous starting cycle.
Table colour codes for multi-coloured signal light (LED)
Status Colour codes Colours
Waiting period «tw», other waiting periods
○…………………
O
Ignition phase, ignition controlled
●○●○●○●○●○●
Blinking yellow
Normal operation
□…………………
Green
Operation, poor ame signal
□○□○□○□○□○
Blinking green
Illegal ame signal during start-up
□▲□▲□▲□▲□▲
Green-Red
Undervoltage
●▲●▲●▲●▲●▲
Yellow-Red
Fault, alarm
▲…………………
Red
Blinking code for fault codes
▲○ ▲○ ▲○ ▲○
Blinking red
Interface diagnostics
▲▲▲▲▲▲▲▲
Red icking
……
Continuous
○
Off
▲
Red
●
Yellow
□
Green
