Parameter Code Summary
PARA-
METER
DESCRIPTION FACTORY
SETTING
RANGE PAGE CUSTOMER
SETTING
02-RVLVL Software Revision 35
03-IRAT Inverter Rated Current A 35
07-FLT3 Last Fault 36
08-FLT2 Second Fault 36
09-FLT1 First Fault 36
12-FOUT Motor Output Frequency 0.00–400.0 Hz 36
13-VOUT Motor Output Voltage 0–100%
of line voltage
36
14-IOUT Motor Output Current 0.00–60.00 A 36
15-LOAD Inverter Load 0–200%
of
03-IRAT
36
17-TEMP Inverter Temperature 0.00–110.0 °C 36
1A-FSTAT Stator-Frequency
(1)
Hz
55 Read-only
21-MODE Input Mode 3
(2)
0–11
36/55
24-FSEL Speed Setpoint Selector 0
(2)
0–19
38/55
31-FMIN Minimum Frequency 0.00 Hz 0.00–400.0 Hz 38
32-FMAX Maximum Frequency 50.00 Hz 20.00–400.0 Hz 38
33-F2 Preset Frequency 2 5.00 Hz 0.00–400.0 Hz 38
34-F3 Preset Frequency 3 20.00 Hz 0.00–400.0 Hz 38
35-F4 Preset Frequency 4 40.00 Hz 0.00–400.0 Hz 38
36-F5 Preset Frequency 5 50.00 Hz 0.00–400.0 Hz 38
37-F6 Preset Frequency 6 0.00 Hz 0.00–400.0 Hz 38
38-F7 Preset Frequency 7 0.00 Hz 0.00–400.0 Hz 38
39-FTL Minimum Frequency in Torque Limit 10.00 Hz 0.00–400.0 Hz 39
41-RSEL Ramp Selector 0
(2)
0–7
39/56
42-ACC1 Acceleration Time 1 3.00 s 0.10–600.0 s 39
43-DEC1 Deceleration Time 1 3.00 s 0.10–600.0 s 39
44-ACC2 Acceleration Time 2 1.00 s 0.10–600.0 s 40
45-DEC2 Deceleration Time 2 1.00 s 0.10–600.0 s 40
46-DECTL Deceleration Time in Torque Limit 1.00 s 0.10–30.00 s 40
47-DCBRK DC Brake Time 0.20 s 0.00–5.00 s 40
48-DCVLT DC Brake Voltage 2/3 of
52-BOOST 0–15% 40
51-VSEL V/Hz Characteristic Selector 0 0–5 40
52-BOOST Voltage Boost 8.00% 0.00–25.00% 41
53-FKNEE V/Hz Knee Frequency 50.00 Hz 26.00–400.0 Hz 42
54-SKBND Skip Frequency Hysteresis Band 1.00 Hz 0.20–20.00 Hz 42
55-SK1 Skip Frequency 1 0.00 Hz 0.00–400.0 Hz 42
56-SK2 Skip Frequency 2 0.00 Hz 0.00–400.0 Hz 42
57-SK3 Skip Frequency 3 0.00 Hz 0.00–400.0 Hz 42
59-MVOLT Rated Motor Voltage 230/400 V 185–240 V;
370–480 V
42
5B-MSAT Motor Saturation Level 47% 15–80% 42
61-LTLF Load Torque Limit Forward 150% 10–150% 42
