Bernette B05 Academy - Sewing Table with Accessory Box; Raising or Lowering the Feed Dog; Using the Slide-On Table

Sewing preparation
20
2020-09 EN 5220205.00A.04
2.4 Sewing table with accessory box
The sewing table has an integrated accessory box.
> To remove the sewing table, hold the sewing table by the handle (1) and pull it away to the left.
1
> To open the accessory box, tilt the cover towards you.
> To close the accessory box, fold the lid downwards at an angle.
2.5 Raising or Lowering the Feed dog
> To raise the feed dog, push the feed dog lever to the right.
– The feed dog is raised when the first stitch is sewn.
> Slide the «Feed dog lever» left to lower the feed dog.
– The feed dog is lowered.
2.6 Using the slide-on table
The extension table, attached to the free arm, enables the available sewing area to be extended.
The height of the extension table can be adjusted by turning the adjustable feet.
Prerequisite:
• The sewing table is removed.
> Unfold the feet on the extension table.
