Maintencance and cleaning
72
2020-09 EN 5220205.00A.04
> Insert the bobbin case.
Note: The markings of the bobbin case and the stitch plate must be aligned identically.
> Fit the stitch plate.
> Fit the bobbin cover.
> Fit the needle and presser foot.
8.3 Oiling the needle bar
Without lubrication, the needle bar may not move smoothly. If the machine is used frequently, the needle
bar must be oiled every six months in order to prevent a blockage.
WARNING
Electronically driven components
Risk of injury near the needle bar.
> Switch off the machine and disconnect it from the power supply.
> Remove the protective cap (1) and screw (2).
> Remove the stand head cover (3).
– Watch out for moving parts after the stand head cover has been removed.
> Apply a drop of oil to the movement mechanism of the needle bar, including the connecting rod/needle
bar, needle bar holder and needle bar holder (apply oil to the points marked with an arrow).
