Bernette B05 Academy - Cleaning the Hook

Maintencance and cleaning
71
2020-09 EN 5220205.00A.04
> Attach the presser foot.
> Connect the machine to the mains power and switch it on.
8.2 Cleaning the hook
CAUTION
Electronically driven components
Risk of injury near the needle and the hook.
> Raise the presser foot.
> Switch off the machine and disconnect it from the power supply.
> Remove the presser foot and the needle.
> Remove the stitch plate.
> Clean the bobbin case with the brush.
> Set needle to topmost position.
> Remove the bobbin case.
> Clean the shuttle race with the brush.
