Bernette b48 FUNLOCK - Threading the Upper Looper (Blue)

22
Threading the Upper Looper (Blue)
– Raise the presser foot to open the tension
discs.
– Thread the upper looper as indicated (1)–(8).
2
2
1
3
2
1
3
8
6
4
5
7
3
2
2
1
3
2
1
3
8
6
4
5
7
3
CAUTION:
Be sure to turn off power switch.
– Pass thread from back to the front through the
thread guide (1).
– Thread the pre-tension guide by pulling the
thread towards the right until it slips under guide
(2). Then pull thread along the right side of pre-
tension as illustrated.
– While holding thread with fingers, pass it
between the tension discs and pull thread down
to make certain it is properly located in between
the tension discs (3).
