Bernette b48 FUNLOCK - Threading the Overlock Right Needle (Green)

 27
Threading the Overlock Right Needle
(Green)
(B On Needle Clamp)
– Raise the presser foot to open the tension
discs.
– Thread the right needle as indicated (1)–(10).
4
5
11
C
10
D
B
A
9
8
7
6
10
11
8
4
5
7
6
3
2
9
1
10
1
2
2
3
6
7
8
9
5
4
10
3
CAUTION:
Be sure to turn off power switch.
– Pass thread from back to the front through the
thread guide (1).
– Thread the pre-tension guide by pulling the
thread towards the right until it slips under guide
(2). Then pull thread along the right side of pre-
tension as illustrated.
– While holding thread with fingers, pass it
between the tension discs and pull thread down
to make certain it is properly located in between
the tension discs (3).
