Bernette b48 FUNLOCK - Threading the Coverstitch Needles; Right Coverstitch Needle (Blue)

30
1
2
2
8
4
5
7
6
3
10
1
3
3
9
2
– Thread the pre-tension guide by pulling the
thread towards the left until it slips under guide
(2). Then pull thread along the right side of pre-
tension as illustrated.
– While holding thread with fingers, pass it
between the tension discs and pull thread down
to make certain it is properly located in between
the tension discs (3).
Threading the Coverstitch Needles
• Right Coverstitch Needle (Blue)
(E On Needle Clamp)
– Raise the presser foot to open the tension
discs.
– Thread the right coverstitch needle as indicated
(1)–(10).
1
2
2
8
4
5
7
6
3
10
1
3
3
9
2
CAUTION:
Be sure to turn off power switch.
– Pass thread from back to the front through the
thread guide (1).
