Bernette b48 FUNLOCK - Threading the Lower Looper (Red)

 23
Threading the Lower Looper (Red)
– Raise the presser foot to open the tension
discs.
– Thread the lower looper as indicated (1)–(9).
– Pass thread from back to the front through the
thread guide (1).
– Thread the pre-tension guide by pulling the
thread towards the right until it slips under guide
(2). Then pull thread along the right side of pre-
tension as illustrated.
– Thread the looper area of the machine following
the blue color coded thread guides (4)–(8).
– Thread the hole in the upper looper from front
to back (8).
8
7
8
4
8
9
1
1
2
2
6
10cm
(4")
6
5
5
7
2
3
4
7
5
8
7
8
4
8
9
1
1
2
2
6
10cm
(4")
6
5
5
7
2
3
4
7
5
8
7
8
4
8
9
1
1
2
2
6
10cm
(4")
6
5
5
7
2
3
4
7
5
PLEASE NOTE:
Make sure thread passes behind lower looper.
Use of tweezers in the looper cover will make
needle eye threading easy.
