SPECIFICATION
Technical Summary
Stitch Formations 23 stitches
1-3 needles
2 loopers
Needle system ELx705
Cutting width 5-7 mm from the left needle
3-5 mm from the right needle
Stitch length 1-4 mm (standard: rolled hemming 1-2, ordinary overlock N=2.5)
Differential feed stretching 0.6 - 1
gathering 1 - 2
Presser foot lift 4.5 mm
Sewing Light LED
Sewing speed 1300 stitches/max.
Foot control Type 4C-316B for (USA/Canada) Type 4C-316C / 4C-326G / 4C-345G
for other countries
Dimensions (L x B x H) mm 360 x 300 x 290
Weight (kg) 7.8 kg
EN – 06/2017 – 4rd Edition
5040007.0.04 / G8P03
© BERNINA International AG
Steckborn CH, www.bernina.com
