ANGLEMASTER
BERNHARD AND COMPANY LTD
Bilton Road • Rugby • England • CV22 7DT
Tel
+
44 1788 811600 • Fax
+
44 1788 812640
Email: info@bernhard.co.uk
USA Toll Free 1-888 GRIND IT
(
1-888 474 6348
)
AM3000 Precision Bedknife Grinder
Contents
Identication of Pictograms 3
Control Box Layout 4
Understanding the Machine 5
Safety 6
Set Up and Installation 7
Setting Up 9
Setting Angles of Cut 13
Electrical Fault Finding 16
Maintenance 18
Parts List 19
Wiring Diagrams 35
Bedknife Mounting Guide 38
AM3000_2007/02/ENG/Membrane Control Panel
Please quote this serial number on all
correspondence:
Serial #:
You are now the owner/operator of a Bernhard’s Anglemaster 3000 which,
if cared for and operated correctly, will give you years of good service.
This manual will enable you to obtain the best results from your Anglemaster so
please read it thoroughly before using your machine.
If you have any service or operational problems contact your distributor,
or phone our
Technical Helpline (USA only) – 1-888 474 6348
or
Bernhard and Company Ltd, England – (+44) 1788 811600
or email
techsupport@bernhard.co.uk
or use the technical support feedback form on our web site
www.expressdual.com or www.bernhard.co.uk
When ordering spare parts please quote the machine type and serial number.
THE MANUFACTURERS ACCEPT NO RESPONSIBILITY FOR ANY SITUATION
ARISING FROM THE FITTING AND/OR USE OF NON-GENUINE SPARE PARTS.
