7. Parts List (Continued)
Ref # Name of Part Qty. Part #
MAIN MOTOR AND SLIDE ____________________________________
1 Motor Plate ..............................................................................1 A4076
2 Motor Plate Slide R.H..............................................................1 A4305
3 Motor Plate Slide L.H. .............................................................1 A4077
4 Carriage Feedscrew................................................................ 1 A9213
5 Siko Counter Support Block.................................................... 1 A4124
6 Siko Counter Insert ................................................................. 1 A9115
7 Motor Slide Nut........................................................................ 1 A4040
8 Siko Counter............................................................................1 A6771
9 Handwheel ..............................................................................1 A6106
10 Diamond Dresser .................................................................... 1 A6737
11 10mm Collar small...................................................................1 A5105
12 Spacer ..................................................................................... 1 A9030
13 Locking Knob........................................................................... 1 A6105
14 4 Lobe Knob 50mm ................................................................. 1 A6103
15 Spring 12mm o/d x 60 ............................................................. 2 A6711
16 Diamond Dresser Shaft........................................................... 1 A9029
17 Diamond Dresser Holder ........................................................1 A6738
18 Motor Spacer Plate (short)...................................................... 1 R4114
19 Motor Spacer Plate (long) ....................................................... 1 R4113
20 Motor 60 Hz............................................................................. 1 A6006
Motor 50Hz.............................................................................. 1 A6004
Motor 3 Phase .........................................................................1 A6005
21 Hex Head Bolt M8 x 25 ...........................................................4 A5723
22 Washer M8 ............................................................................ 12 A5321
23 Grinding Wheel Ext. Shaft ......................................................1 A9053
24 Grinding Wheel Parallel Cup................................................... 1 A6507
Grinding Wheel Taper Cup...................................................... 1 A6520 (not shown)
25 Mills Pin M6 x 10 ..................................................................... 1 A5468
26 Extension Shaft Flange...........................................................1 A9054
27 Extension Shaft Nut ................................................................ 1 A9055
28 Socket Cap Head Screw M6 x 25 ..........................................1 A5152
29 Socket Screw M5 x 5............................................................... 1 A5137
30 Socket Set Screw M5 x 10 ...................................................... 1 A5131
31 Socket Screw M6 x 6............................................................... 1 A5156
32 S’k’t Cap H’d Screw M6 x 20...................................................8 A5150
33 Washer M12 (special).............................................................. 1 A5487
34 Socket Set Screw M5 x 10 ...................................................... 1 A5131
35 Socket Screw M12 x 20...........................................................1 A5486
36 Crinkle Washer M12 ................................................................1 A5325
37 Washer M12 ............................................................................1 A5315
38 Socket Cap Head Screw M6 x 20 ...........................................2 A5150
29
ANGLEMASTER • AM3000
© Bernhard and Company Limited
