7. Parts List (Continued)
Ref # Name of Part Qty. Part #
MOUNTING BAR ____________________________________________
1 Mounting Bar ........................................................................... 1 A4081
2 Magnet..................................................................................... 2 A6753
3 Mounting Bar Block R.H.......................................................... 1 A4083
4 Mounting Bar Block L.H. ......................................................... 1 A4082
5 Mounting Bar Pointer L.H........................................................ 1 A6339
6 Kip Lever M12 x 80..................................................................1 A6196
7 Washer M12 ............................................................................3 A5314
8 Mounting Bar Pointer R.H. ......................................................1 A6340
9 Button Head Screw M6 x 8 .....................................................4 A5158
10 Mounting Bar Feedscrew ........................................................ 2 A5417
11 M’ting Bar F’screw Handwheel ...............................................2 A6135
12 Single Coil Washer M12..........................................................4 A5312
13 Nut M12 ...................................................................................4 A5506
14 Mounting Bar Lever ................................................................. 1 A9070
15 Ball Knob ................................................................................. 1 A6134
16 Angle Potentiometer Bracket ..................................................1
17 Mounting Screws.....................................................................2
18 Angle Potentiometer ...............................................................1
19 Grun Screw .............................................................................1
20 Soleplate Casting L.H. ............................................................ 1 A4130
21 Soleplate Casting R.H............................................................. 1 A4131
22 Quadrant Plate ........................................................................ 2 A4302
23 Eccentric Pin ........................................................................... 2 A9031
24 S’plate Casting Retaining Strip ............................................... 2 A4132
25 C’s’k Socket Screw M4 x 8 ...................................................... 4 A5127
26 Kip Lever M10 x 30..................................................................2 A6119
27 Washer M10 ............................................................................4 A5310
28 Kip Lever M10 x 15..................................................................2 A6181
29 Captive Nut M10......................................................................2 A9023
30 Taper Pin .................................................................................2 A9119
31 Taper Pin Plate ........................................................................2 A4089
32 Eccentric Pin Handle...............................................................2 A4184
33 Ball Knob .................................................................................2 A6115
34 Lever Stop ............................................................................... 2 A9062
35 Nut M8 ..................................................................................... 2 A5519
36 Circlip 25mm ...........................................................................2 A5603
37 Mounting Bar Finger................................................................2 A4085
38 Spring M8 x 30 ........................................................................ 2 A6752
39 Nyloc Nut M6........................................................................... 2 A5517
40 Quadrant Pivot Pin .................................................................. 2 A9105
41 Centre Jacking Screw Bracket................................................ 1 A4374
42 Mounting Bar Bracket Boss.....................................................1 A9198
43 Jacking Screw Knob................................................................ 1 A6193
44 Jacking Screw ......................................................................... 1 A5470
45 Thread Extension ....................................................................1 A9197
46 M8 Locking Nut .......................................................................1 A6179
47 Button Hd S’k’t Screw M8 x 12................................................2 A5194
48 Washer M6 .............................................................................. 5 A5320
49 Shoulder Screw M10 x 12 x 25................................................ 4 A5120
50 Button Head Screw M6 x 16 ...................................................2 A5148
51 Wing Knob M6 x 15 ............................................................... 2 A6129
52 Thrust Bearing.........................................................................3 A7738
53 Cover for Thrust Bearing......................................................... 3 A6195
54 ” dia Cup Locator (not shown).............................................. 2 A2733
55 19mm Taper Pin (not shown) .................................................. 2 A9266
56 Hex Head Bolt M12 x 75..........................................................1 A5715
57 Cable Potentiometer to Lyra OCB (Not Shown) .....................1
25
ANGLEMASTER • AM3000
© Bernhard and Company Limited
