7. Parts List (Continued)
Ref # Name of Part Qty. Part #
MAIN FRAME _______________________________________________
1 Main Frame ............................................................................. 1 A4072
2 M’t’g Bar Feedscrew Guard R.H ............................................. 1
3 M’t’g Bar Feedscrew Guard L.H.............................................. 1
4 Rail .......................................................................................... 2 A6717
5 Large Dust Drawer ..................................................................1 A6332
6 Drawer Handle ........................................................................2 A6110
7 Button Head Screw M6 x 8 .....................................................4 A5158
8 Button Head Screw M5 x 6 .....................................................8 A5138
9 Eccentric for Slide Block ......................................................... 4 A9211
10 Bearing .................................................................................... 4 A7723
11 Hex. Head Bolt M6 x 12 ..........................................................4 A5718
12 Rail Adjuster Bolt M10 x 50 ..................................................... 2 A5755
13 Nut M10 ...................................................................................2 A5503
14 Brass Cap................................................................................ 2 A9222
15 Nut M10 ...................................................................................4 A5503
16 Socket Grub Screw M8 x 30 ...................................................8 A5188
17 Reversing Stop ........................................................................ 2 A4115
18 4 Lobe Knob M8 x 45 ..............................................................2 A6133
19 Buffer for Reversing Stop........................................................ 2 A6819
20 Button H’d S’k’t Screw M5 x 10............................................... 2 A5129
21
ANGLEMASTER • AM3000
© Bernhard and Company Limited
