Machine Functions
The ANGLEMASTER has three separate motors driving the grind stone, traverse and
coolant pump respectively. Each has a separate start and stop button on the control panel.
Grind Stone
Directly driven by the main motor at up to 3800 rpm.
Traverse
Powered by a motor/gearbox unit under the grinding head carriage. Drives along a xed,
damped chain run. Traverse is physically engaged using the over-centre lever on the left
front of the carriage.
Coolant pump
Fitted into the top of the coolant reservoir/settlement tank which is located inside the
cabinet in the base of the machine.
Emergency stop
Pressing the large red mushroom headed button will stop ALL motors. The button will be
locked into the off position. No motors will start when their buttons are pressed until the
E-stop is released by twisting the knob counter-clockwise.
