7. Parts List (Continued)
Ref # Name of Part Qty. Part #
TRAVERSE MOTOR AND CARRIAGE __________________________
1 Carriage Plate .........................................................................1 A4023
2 Carriage Plate Slide R.H.........................................................1 A4304
3 Carriage Plate Slide L.H. ........................................................1 A4024
4 Jib Strip ...................................................................................1 A4061
5 Rear Adj. Bearing Block ..........................................................1 A4107
6 Clutch Engagement Bracket ...................................................1 A4292
7 Hex. Head Sp’c’l Set Screw..................................................... 1 A9065
M12 x 40
8 Clutch Shaft............................................................................. 1 A9214
9 Microswitch Mounting Block.................................................... 1 A4075
10 Reversing Bar..........................................................................1 A9110
11 Reversing Bar Support Block.................................................. 2 A4114
12 Traverse Motor 60Hz............................................................... 1 A6023
Traverse Motor 50Hz............................................................... 1 A6021
Traverse Motor 3 phase ..........................................................1 A6020
13 10mm Collar large ...................................................................2 A9006
14 5mm Spring ............................................................................. 2 A6718
15 Grub Screw M6 x 6 ................................................................. 4 A5156
16 Toggle Latch ............................................................................ 1 A6884
17 Halfnut M16 ............................................................................. 1 A5527
18 Grub screw M6 x 30 ................................................................1 A5215
19 Nyloc Nut M12 ......................................................................... 1 A5507
20 Shoulder Bolt M8 x 12 x 6 ....................................................... 1 A5165
21 Bearing .................................................................................... 7 A7713
22 Hex. Head Bolt M12 x 30.........................................................1 A5713
23 Special Washer M12 ...............................................................1 A5211
24 Pan Head Screw M4 x 20........................................................ 2 A5412
25 Microswitch.............................................................................. 1 A8133
26 Cap Head Screw M6 x 25 ..................................................... 11 A5152
27 Nut M6 ..................................................................................... 3 A5516
28 Jib Strip Screw M6 x 40 ..........................................................3 A5111
29 Sprocket .................................................................................. 1 A7606
30 Grub Screw M6 x 10................................................................ 1 A5175
31 Nyloc Nut M6...........................................................................4 A5517
32 C’s’k Socket Screw M10 x 25 .................................................. 6 A5115
33 Cap head Screw M5 x 16 ........................................................ 2 A5132
34 Reversing Bar Actuator ...........................................................1 A9112
35 Traverse Chain ........................................................................1 A4144
36 Chain Tension Bolt .................................................................. 2 A5420
37 Tension Spring ........................................................................2 A6739
38 Nut M10 ...................................................................................4 A5504
39 Chain Link................................................................................ 2 A7502
27
ANGLEMASTER • AM3000
© Bernhard and Company Limited
To Next Page
