BestCode NExT 82 - Pre-Pump Filter (31-0023-01) Replacement

BestCode Next Series 8 Technical Manual October 2022 Page 89 of 290
Pre-Pump Filter (31-0023-01) Replacement
Be familiar with proper safety information for handling fluids.
Procedure Time: 15 minutes
1. Remove the Ink SmartFill cup
Instructions here
2. Locate the Pre-Pump filter
3. Check the tube lengths on the
Pre-pump filter.
The inlet should be 4” and the
outlet tube should be 17”.
If the Pre-Pump
filter is not
mounted vertically,
Phase Faults will
occur.
4. Follow directions from Filter Maintenance, Step 3-8. Instructions here
