BestCode NExT 82 - Barcode Field

BestCode Next Series 8 Technical Manual October 2022 Page 29 of 290
Barcode Field
Video Guide for Barcode Field: https://youtu.be/nWT-W7ZOUgw
Encoding
Selects the type of barcode to be created. The following are available:
Interleaved 2 of 5
UPC-A
UPC-E
EAN 13
EAN 8
Code 39
Code 128
Data Matrix
QR Code
DotCode
Human Readable
Toggles where a human readable version of the barcode data is included into the message editor.
This is not available for Data Matrix or QR Codes.
Checksum
Manual or Auto. With Auto, the Printer will automatically create a checksum value for the code.
Start Code:
Code 128 Only. A, B, or C. Used in programming Code 128 barcodes.
Size
QR Code and Data Matrix only. The height and width dimensions of the coded data.
Keyboard
Brings up the on screen keyboard for typing in text to the barcode.
AutoCode Field
Insert Autocode data into the barcode
User Define
Insert a User Define field into the barcode.
