Peripherals
The Peripherals page varies based on the
selected Network Command mode (See
Network -2 Command Mode).
BestCode Command Mode
Photocells
PE1/PE2
Debounce
Enable or disable debounce on PE1. Used with mechanical switch print triggers. Typical 10-50. If value
necessary over 200, likely Relay needs replacement.
PE1/PE2
Trigger
Changes the state that the Photoeye sends a print trigger
Rise
Print begins when the Photoeye state is up
Fall
Print begins when the Photoeye state is down
PE 1
Option
Always ON
PE 1 Setup
Choose which counters should or should not increment when PE 1 is triggered.
