BestCode NExT 82 - Jet Alignment

BestCode Next Series 8 Technical Manual October 2022 Page 133 of 290
Jet Alignment
Be familiar with proper safety information for handling fluids.
Procedure Time: 5 minutes
1. Loosen the 2 drop generator side
mounting screws by ¼ turn (90°).
2. Use a flathead screwdriver to move the
jet up and down in the gutter hole.
3. Tighten the drop generator side
mounting screws once this position is
achieved.
IDEAL VERTICAL ALIGNMENT
Side View
