BestCode Next Series 8 Technical Manual October 2022 Page 134 of 290
1. Loosen the 1 drop generator adjuster
screw by ¼ turn (90°).
2. Use a flathead screw driver to rotate the
adjuster cam. This moves the jet towards
and away from the print slot.
3. Tighten the drop generator adjuster
screw once this position is achieved.
IDEAL HORIZONTAL ALIGNMENT
Top View
