BestCode Next Series 8 Technical Manual October 2022 Page 94 of 290
For Configuration A:
1. Remove and replace the entire
assembly.
For Configuration B:
1. Disassemble the filter assembly
and discard the inlet side capsule.
2. Remove the Main Ink manifold
3. Remove the Filter using a 12mm
wrench.
Discard the used filter and waste fluid
in accordance with local regulation
Outlet Side
To Printhead
manifold
Inlet Side
From
Dampener
