BestCode Next Series 8 Technical Manual October 2022 Page 137 of 290
After Cutting
6. Slide the clipped back Yellow onto
the Drop generator bleed port.
7. Swage tube open with a
screwdriver
8. Push the tube all the way down
9. Connect the blue coax cable and
heat shrink with the included
heatshrink.
10. Perform jet alignment and
modulation calibration to complete
Jet Alignment Guide
Modulation Calibration Guide
