BestCode NExT 82 - Page 166

BestCode Next Series 8 Technical Manual October 2022 Page 152 of 290
5. Lift out the Ink Manifold and remove the
Blue, White, and Yellow tubes.
6. Remove Red tube from the outlet of the
Dampener or Printhead Filter.
See Dampener removal instructions here.
7. Cap the tubes to reduce the mess.
8. Pull the umbilical hoses and cables out
through the umbilical bulked fitting.
