BestCode Next Series 8 Technical Manual October 2022 Page 211 of 290
Additional Phase Tests
Test
Meaning
Does the printer
produce ink droplets?
This means that the 300V circuit of the printer is working correctly. Issue is likely not with the
Main Board.
Print test with Errors
and Phase Off
If the system will print with the errors and phasing off (even if quality is very poor), the 300V
circuit is working, and the issue is likely not the Main Board.
Manual Phase Test
Step 1: With the jet off, rub the Phase Detector with your finger.
Step 2: Look for flickering on LED 14 on the Main Board.
If the flicking corresponds to finger contact on the phase, the issue is likely not with the
Printhead.
If the light is constantly On or Off, the issue is likely with the printhead.
