1. Secure the printhead into the printhead clamp.
Clamp is included with:
Kit 40-0003-01 Printhead Floor Mount
Kit 40-0004-01 Printhead Conveyor Mount
2. The gutter should always be towards the floor.
3. Keep the gap between the product and the print slot
at 1/16”-1/2” inch.
4. Keep printhead square to the product to prevent
print distortion.
A 5°-10° angle between head and product may be
necessary in high static environments.
