UNITE – Technical specifications
34
. Technical specifications
Unite RP, RP-T
DECT RF frequency range . . . . . . . . . . . . . . . . . . . . . . . . . . 1880 - 1930 MHz, depending on the country
DECT transmission power . . . . . . . . . . . . . . . . . . . . . . . . . . . up to 250 mW (peak), depending on the country
DECT operating range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . up to 300 m outside (line of sight);
the actual operating range depends upon the
RF output settings, the surroundings, the signal absorption,
signal reflection and signal interference
Audio bandwidth
Low quality (SD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 Hz - 7 kHz (-3 dB)
High quality (HD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 Hz - 14 kHz (-3 dB)
Operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Broadcast and/or full-duplex on all routes
Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AES-256 bit encryption
Headphone/headset/induction loop connector. . . . 4-pin mini jack, 3.5 mm, CTIA Standard
Integrated microphone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . yes
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . monochrome white OLED display with high contrast
Max. number of open microphones. . . . . . . . . . . . . . . . . 3 (individual level control for each microphone)
Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . lithium-ion battery pack, replaceable by service staff only
Battery monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Battery status of remaining capacity via OLED display
Operating time of battery pack. . . . . . . . . . . . . . . . . . . . . > 15 hrs., typ.
Side-tone and microphone gain. . . . . . . . . . . . . . . . . . . . individually adjustable
USB Type C connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . USB 2.0/3.0 standard, compatible to 5 V power supplies only,
power consumption max. 500 mA
Strap anchor points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . available, neck strap removable
Dimensions (W x H x D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 x 102 x 15.5 mm
Weight (incl. battery). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 g
Temperature range
Charging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to +35 °C
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -10 to +40 °C
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -20 to +50 °C
Relative humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 to 90%
Unite TP
DECT RF frequency range . . . . . . . . . . . . . . . . . . . . . . . . . .1880 - 1930 MHz, depending on the country
DECT transmission power . . . . . . . . . . . . . . . . . . . . . . . . . .up to 250 mW (peak), depending on the country
DECT operating range . . . . . . . . . . . . . . . . . . . . . . . . . . . . .up to 300 m outside (line of sight); the actual operating
range depends upon the RF output settings,
the surroundings, the signal absorption,
signal reflection and signal interference
Audio bandwidth
Low quality (SD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200 Hz - 7 kHz (-3 dB)
High quality (HD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 Hz - 14 kHz (-3 dB)
Operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Broadcast and/or full-duplex on all routes
Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AES-256 bit encryption
Headphone/headset/induction loop connector . . . 4-pin mini jack, 3.5 mm, CTIA Standard
Microphone connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-pin mini XLR jack, male
(4.5 V bias voltage, beyerdynamic TG pin assignment)
Integrated microphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . yes
Line-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . mini jack, 3.5 mm, max. -6 dBV / 0.5 V RMS
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . monochrome white OLED display with high contrast
Max. number of open microphones . . . . . . . . . . . . . . . . 3 (individual level control for each microphone)
Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . lithium-ion battery pack, replaceable by service staff only
Battery monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Battery status of remaining capacity via OLED display
Operating time of battery pack. . . . . . . . . . . . . . . . . . . . > 15 hrs., typ.
Side-tone and microphone gain . . . . . . . . . . . . . . . . . . . individually adjustable
Bluetooth® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V4.2 (HFP - Hands-Free-Profile, A2DP - Audiostreaming)
USB Type C connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . USB 2.0/3.0 standard, compatible to 5 V power supplies only,
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . power consumption max. 500 mA
Strap anchor points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . available, neck strap removable
Dimensions (W x H x D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 x 102 x 15.5 mm
Weight (incl. battery). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 g
+4.5V
4
3
2
1
Audio
20k
