Chapter2. Installation 11
Chapter2.
Installation of Beyonwiz T3
This chapter will guide you through the whole installation process of Beyonwiz T3. Please read
each section carefully to make sure that the system runs properly.
2.1 Connecting Antenna Cables
Beyonwiz T3 is integrated with triple digital tuners, and one of the first steps is to connect
antenna cable(s) to Beyonwiz T3 in order to gain optimal signal quality. You can either choose
one of the following connection methods depending on the equipment you have.
A. External Loop-through
Where you have only one Antenna cable, connect the cable to TUNER 1 Input and
then use the provided loop cables to loop the signal through to the other tuners as
pictured.
