BFT Espas 20I - 13 Configuration Menu Structure

42 - Espas 20I
D812913 10598_02
13 - CONFIGURATION MENU STRUCTURE
The Deneb control board is tted with a 16-character LCD display and a 5-contact joystick.
The station can be congured in a lot of dierent ways. To enter menu 2 “ADMIN” when the
station is switched on, wait for the rmware version and the date to appear and press the
joystick centrally.
DEVICE STATUS OK
WORK= NORMAL
GRACE TIME = 000
OPERATOR CARDS
CLEAR COUNTER
Date Mo 23/02/12
time 15:12:36
sacs easy access
2.15 mar 29 2016
TEMPER. = 27.00
Input= --------
3 sec.
Startup
PUSH
3 sec.
MENU 2
MENU 1
Language = IT
Address = 033
Warmer Thr. = 018
GateT = In 1
DELETTE CARDS
Printer T. = X56
Adel1 Bar.1 = 330
Adel Bar. 2 = 330
MENU 2
Adel Pres. = NO
Codif. Sup. = NO
Adel Capt. = NO
Loop Time = 006
No Mouth F. = YES
RUN LOADER
PUSH
RESET
