Prepare the entrance/exit in order to make it easy for cars to approach the station. Avoid tight
bends immediately before or after the station. Keep the access lane as at as possible but,
above all, avoid laying lanes on an uphill slant.
Attention: for further details, see the installation diagrams.
9 - ASSEMBLY, ANCHOR POSITIONING
10 - LOOP POSITIONING
We recommend loops are installed as shown in the following drawings:
175
50
150
280
100
20
200
10
130
150
20
30 30
30
70
24,5
31
400
300
200
200
espas20 I
60
Espas 20I
