BIFFI FAIL SAFE ELECTRIC ACTUATORS, MODEL EFS2000V4
InstructIon and operatIng Manual
PARTS LIST
Item Quantity Description Material
1 1 Head spring flange Carbon steel
2 4 Washer -
3 4 Tie Rod Alloy steel
4 4 Screw Alloy steel
5 2 Gasket Fiber
6 4 Retainer ring Stainless ring
7 1 Spring thrust flange Cast iron
8 1 Spring Alloy steel
9 1 Spring Alloy steel
10 1 Bush Carbon steel-Bronze-PTFE
11 1 Spring guide flange Cast iron
12 1 Spring guide rod Alloy steel
13 1 Spring cartridge tube Carbon steel
14 1 Spring cartridge tube Carbon steel
15 2 End spring flange Carbon steel
16 4 Nut Carbon steel
17 1 Adjusting screw Carbon steel
18 1 Gasket NBR rubber
19 1 Washer Carbon steel
20 1 Nut Carbon steel
