Big Dutchman Viper Basic-Step - Stir Fan

User Manual • Basic-Step 25
Viper Climate and Production Computer
2.2.8 Stir Fan
Stir fan 1-6
Mode
24-hour clock
Temperature
Heater
24-hour clock
Start time
Stop time
ON-time
OFF-time
Temperature
Control One sensor
Two sensors
Sensors installed
One sensor
Sensor no.
One sensor
Stir fan temp.
Two sensors
High temp. sensor no.
Two sensors
Low temp. sensor no.
Two sensors
Stir fan temp.
ON-time
OFF-time
Heater
Control
Together
Separate
Start delay
Together
Stop delay
Seperate
Runtime
Table 12: Survey of the menu for stir fans (changeable values are highlighted in bold types).
A stir fan improves circulation of the air and thus provides a more uniform temperature in the
livestock house.
The Viper can regulate up to six stir fans at a time. Each stir fan can be regulated in connection with a
heat source, a temperature sensor or a 24-hour clock.
Controller Stir fan – method of operation
Heat source
(up to 6)
1) Together: The stir fan runs while the heat source supplies heat, but starts and
stops with a set time delay (Start delay/Stop delay).
2) Separate: The stir fan runs after the heat source has supplied heat. It starts
with a time delay (
Start delay) and runs for a set period of time (Runtime).
Temperature
sensor (up to 2)
1) One temperature sensor: The stir fan runs for a set ON-time, when the
temperature deviates more than set in Temperature setpoint.
2) Two temperature sensors: The stir fan runs for a set ON-time at a set
temperature difference between the two sensors.
24-hour clock
1) The stir fan runs for a set ON/OFF-time at set times.
