BIGTREETECH CB2 User Manual
10
175
B connector_75
MIPI_DSI_TX1_D0N
176
B connector_76
HTX1P
HDMI TX1 Positive.
177
B connector_77
MIPI_DSI_TX1_D0P
178
B connector_78
HTX1N
HDMI TX1 Negative.
179
B connector_79
GND
180
B connector_80
GND
181
B connector_81
MIPI_DSI_TX1_D1N
182
B connector_82
HTX0P
HDMI TX0 Positive.
183
B connector_83
MIPI_DSI_TX1_D1P
184
B connector_84
HTX0N
HDMI TX0 Negative.
185
B connector_85
GND
186
B connector_86
GND
187
B connector_87
MIPI_DSI_TX1_CLKN
188
B connector_88
HTXCP
HDMI CLK Positive.
189
B connector_89
MIPI_DSI_TX1_CLKP
190
B connector_90
HTXCN
HDMI CLK Negative.
191
B connector_91
GND
192
B connector_92
GND
193
B connector_93
MIPI_DSI_TX1_D2N
194
B connector_94
MIPI_DSI_TX1_D3N
195
B connector_95
MIPI_DSI_TX1_D2P
196
B connector_96
MIPI_DSI_TX1_D3P
197
B connector_97
GND
198
B connector_98
GND
199
B connector_99
HSDA
HDMI I2C
200
B connector_100
HSCL
HDMI I2C
