BIGTREETECH CB2 User Manual
9
130
B connector_30
USB3-DP
131
B connector_31
GND
132
B connector_32
GND
133
B connector_33
MIPI_CSI_RX_D2N
134
B connector_34
MIC1_IN
135
B connector_35
MIPI_CSI_RX_D2P
136
B connector_36
MIC2_IN
137
B connector_37
GND
138
B connector_38
GND
139
B connector_39
MIPI_CSI_RX_D3N
140
B connector_40
MIPI_CSI_RX_CLK1N
141
B connector_41
MIPI_CSI_RX_D3P
142
B connector_42
MIPI_CSI_RX_CLK1P
143
B connector_43
GPIO4_A7
144
B connector_44
GND
145
B connector_45
HP_SNS
146
B connector_46
USB2_HOST2_DP
147
B connector_47
HP_DET_L
148
B connector_48
USB2_HOST2_DM
149
B connector_49
SARADC_VIN2
150
B connector_50
GND
151
B connector_51
HCEC
HDMI CEC
152
B connector_52
USB3_HOST1_DP
153
B connector_53
HHPD
HDMI Hotplug
154
B connector_54
USB3_HOST1_DM
155
B connector_55
GND
156
B connector_56
GND
157
B connector_57
MIPI_DSI_TX0_D0N
158
B connector_58
USB3_HOST1_SSTXP
159
B connector_59
MIPI_DSI_TX0_D0P
160
B connector_60
USB3_HOST1_SSTXN
161
B connector_61
GND
162
B connector_62
GND
163
B connector_63
MIPI_DSI_TX0_D1N
164
B connector_64
USB3_HOST1_SSRXP
165
B connector_65
MIPI_DSI_TX0_D1P
166
B connector_66
USB3_HOST1_SSRXN
167
B connector_67
GND
168
B connector_68
GND
169
B connector_69
MIPI_DSI_TX0_CLKN
170
B connector_70
HTX2P
HDMI TX2 Positive.
171
B connector_71
MIPI_DSI_TX0_CLKP
172
B connector_72
HTX2N
HDMI TX2 Negative.
173
B connector_73
GND
174
B connector_74
GND
