BIGTREETECH CB2 - Page 8

BIGTREETECH CB2 User Manual
8
86
A connector_86
3V3
3.3v out /200mA
87
A connector_87
VCC_5V
5V IN /2A
88
A connector_88
1V8
1.8v out /100mA
89
A connector_89
GPIO3_B4
90
A connector_90
1V8
1.8v out /100mA
91
A connector_91
NC
92
A connector_92
PWRON
93
A connector_93
RECOVERY
94
A connector_94
NC
95
A connector_95
GPIO4_A1
96
A connector_96
NC
97
A connector_97
GPIO4_A5
98
A connector_98
GND
99
A connector_99
PMIC_PWRON
100
A connector_100
AP-RESET
101
B connector_1
USB_OTG0_ID
102 B connector_2
PCIE20_CLKREQn_M
2
103
B connector_3
USB_OTG0_DM
104
B connector_4
LINEOUTL
105
B connector_5
USB_OTG0_DP
106
B connector_6
LINEOUTR
107
B connector_7
GND
108
B connector_8
GND
109
B connector_9
PCIE20_PERSTn_M2
110
B connector_10
PCIE20_REFCLKP
111
B connector_11
GPIO4_B0
112
B connector_12
PCIE20_REFCLKN
113
B connector_13
GND
114
B connector_14
GND
115
B connector_15
MIPI_CSI_RX_D0N
116
B connector_16
PCIE20_RXP
117
B connector_17
MIPI_CSI_RX_D0P
118
B connector_18
PCIE20_RXN
119
B connector_19
GND
120
B connector_20
GND
121
B connector_21
MIPI_CSI_RX_D1N
122
B connector_22
PCIE20_TXP
123
B connector_23
MIPI_CSI_RX_D1P
124
B connector_24
PCIE20_TXN
125
B connector_25
GND
126
B connector_26
GND
127
B connector_27
MIPI_CSI_RX_CLK0N
128
B connector_28
USB3-DM
129
B connector_29
MIPI_CSI_RX_CLK0P
