BIGTREETECH CB2 User Manual
7
41
A connector_41
GPIO0_C4
42
A connector_42
GND
43
A connector_43
GND
44
A connector_44
GPIO3_C1
45
A connector_45
GPIO4_A3
46
A connector_46
GPIO1_A1
47
A connector_47
GPIO4_C6
48
A connector_48
GPIO1_A0
49
A connector_49
GPIO0_C0
50
A connector_50
GPIO0_C7
51
A connector_51
GPIO0_D0
DEBUG UART
52
A connector_52
GND
53
A connector_53
GND
54
A connector_54
GPIO3_A1
55
A connector_55
GPIO0_D1
DEBUG UART
56
A connector_56
GPIO4_B3
57
A connector_57
SDC0-CLK
SDCARD Clock signal
58
A connector_58
GPIO4_B2
59
A connector_59
GND
60
A connector_60
GND
61
A connector_61
SDC0-D3
SDCARD Data3 signal
62
A connector_62
SDC0-CMD
SDCARD CMD signal
63
A connector_63
SDC0-D0
SDCARD Data0 signal
64
A connector_64
NC
65
A connector_65
GND
66
A connector_66
GND
67
A connector_67
SDC0-D1
SDCARD Data1 signal
68
A connector_68
NC
69
A connector_69
SDC0-D2
SDCARD Data2 signal
70
A connector_70
NC
71
A connector_71
GND
72
A connector_72
NC
73
A connector_73
GPIO0_B5
74
A connector_74
GND
75
A connector_75
GPIO3_D2
76
A connector_76
GPIO3_D3
SDCARD detect
77
A connector_77
VCC_5V
5V IN /2A
78
A connector_78
NC
79
A connector_79
VCC_5V
5V IN /2A
80
A connector_80
GPIO4_B5
81
A connector_81
VCC_5V
5V IN /2A
82
A connector_82
GPIO4_B4
83
A connector_83
VCC_5V
5V IN /2A
84
A connector_84
3V3
3.3v out /200mA
85
A connector_85
VCC_5V
5V IN /2A
