BA-EN-HydroStar V3.1 page 3
BGA 215 BGA 430
Supply voltage 230 VAC 230 VAC
Frequency range 47 – 63 Hz 47 – 63 Hz
Rated current 8 A 16 A
Starting current (typical) 60 A 60 A
Rated power 1500 VA 3000 VA
Motor
Motor type 1 Brushless DC motor
(BLDC)
2 Brushless DC motors
(BLDC)
Rated voltage 24 VDC 24 VDC
Rated current 40A 2 x 40A
Rated rotational speed 2400 min
-1
2400 min
-1
Turbine
Discharge rate 65 – 215 m³/h 130 – 430 m³/h
Speed (turbine outlet) 1.0 – 3.2 m/s 1.0 – 3.2 m/s
Water temperature +5° C to +40° C +5° C to +40° C
Immersion depth 0.20 m – 1.00 m 0.20 m – 1.00 m
BGA 275 BGA 550
Supply voltage 230 VAC 230 VAC
Frequency range 47 – 63 Hz 47 – 63 Hz
Rated current 8 A 16 A
Starting current (typical) 60 A 60 A
Rated power 1700 VA 3400 VA
Motor
Motor type 1 Brushless DC motor
(BLDC)
2 Brushless DC motors
(BLDC)
Rated voltage 24 VDC 24 VDC
Rated current 50A 2 x 50A
Rated rotational speed 2400 min
-1
2400 min
-1
Turbine
Discharge rate 80 – 275 m³/h 160 – 550 m³/h
Speed (turbine outlet) 1.0 – 3.2 m/s 1.0 – 3.2 m/s
Water temperature +5° C to +40° C +5° C to +40° C
Immersion depth 0.20 m – 1.00 m 0.20 m – 1.00 m
2.1.2 Information for the user / target group
This documentation contains the necessary information for proper use of the products described
therein. It is intended for technically qualified personnel.
Qualified personnel are persons who - because of their education, experience, instructions, and
knowledge about corresponding standards and regulations, rules for the prevention of accidents, and
operating conditions - are authorised by the person responsible for the safety of the machine to
perform the required actions and who are able to recognise and avoid potential hazards (definition of
qualified personnel according to IEC 364)
