KB 23 / KB 23-UL (E3.1) 02/2019 page 54/87
2. Entering the time program to the program editor
Program table for the example program:
Section
SEC
Temperature
set-point
[ °C]
TEMP
Section length
[hh.mm]
TIME
Fan speed
[%]
FAN
Operation lines
O.LINE
S01
20
119:59
100
000
S02
20
000:01
100
000
S03
5
047:59
100
000
S04
5
000:01
100
000
In this example the program will be entered to the first program place (P01).
Normal display
Press key
for 5 sec.
Display 1 shows
e.g. 0000
Display 2 shows
PROGRAM EDITOR
(you are in the program editor)
Press program key
Display 1 shows
0000
Display 2 shows
UserCod? 0000
(enter user code)
Enter user code using arrow keys
e.g. 0001
(basic setting, adjustable in the user level,
chap. 10).
Value is shown in both displays.
Automatically forward after 2 sec.
Display 1 shows
01
program P01 selected
Display 2 shows
alternating
---:--- PRG.
program can be selected
CONTINUE X/W
(information: to 1
st
program section with X/W)
Select program P01 using arrow keys
Value is shown in Display 1.
Press key
In the selected program P01 the first program section S01 is shown:
Display 1 shows
01
section S01 has been selected
Display 2 shows
alternating
P01: --- SEC.
enter new set-points for the individual variables with button
X/W.
CONTINUE X/W
or
NEW SEC. X/W
Select section S01using arrow keys
Press key
Display 1 shows
20.0
C
(actual temperature set-point)
Display 2 shows
alternating
S01: TEMP 20.0
(variable: temperature in °C)
CONTINUE X/W
(information: go on with X/W)
Entry of temperature set-point of 20 °C
using arrow keys
