Press key
Display 1 shows
119
(actual section length set-point)
Display 2 shows
alternating
S01: TIME 119:59
(variable: section length in hhh:mm)
CONTINUE X/W
(information: go on with X/W)
Enter section length set-point of S01 of 119
hs. 59 min. using arrow keys
Value is shown in both displays.
Press several times key
until P01: --- SEC appears:
Display 1 shows
02
section S02 has been selected
Display 2 shows
alternating
P01: --- SEC.
enter new set-points for the individual variables with button
X/W.
CONTINUE X/W
or
NEW SEC. X/W
Select section S02 using arrow keys
Press key
Display 1 shows
20.0
C
(actual temperature set-point)
Display 2 shows
alternating
S02: TEMP 20.0
(variable: temperature in °C)
CONTINUE X/W
(information: go on with X/W)
Entry of temperature set-point of 20 in °C of
S02 using arrow keys
Press key
Display 1 shows
000
(actual section length set-point)
Display 2 shows
alternating
S02: TIME 000:01
(variable: section length in hhh:mm)
CONTINUE X/W
(information: go on with X/W)
Enter section length set-point of S02 of 1
min using arrow keys
Value is shown in both displays.
Press several times key
until P01: --- SEC appears:
Display 1 shows
03
section S03 has been selected
Display 2 shows
alternating
P01: --- SEC.
enter new set-points for the individual variables with button
X/W.
CONTINUE X/W
or
NEW SEC. X/W
Select section S03using arrow keys
Press key
Display 1 shows
5
C
(actual temperature set-point)
Display 2 shows
alternating
S02:TEMP 5
(variable: temperature in °C)
CONTINUE X/W
(information: go on with X/W)
Entry of temperature set-point of 5 °C
of S03
using arrow keys
