Page #102 background image
Manual for VMP300-based instruments
94
10. Technical Specifications
10.1 Equipment Ratings
10.1.1 Electrical & Mechanical specifications
Table 10: Instrument electrical ratings.
Instrument
type
Input
Output
Mechanical
Voltage
Range/
Vac
Frequen
cy
range/H
z
Power
max/
W
Fuses
a
Voltage Range/Current
Size
(HxWxD)/mm
Weight
without
cable/kg
SP-200
[90;264]
[50; 60]
350
2 x 4 AF
10 Vdc / 500 mA
221x170x384
7.2
SP-240
[90;264]
[50; 60]
350
2 x 4 AF
10 Vdc / 500 mA
or 14 Vdc / 4A (with 4A/14V
booster)
225x205x410
7.5
SP-300
[90;264]
[50; 60]
350
2 x 4 AF
10 Vdc / 500 mA
or 48 Vdc/1A (with 1A/48V booster)
or 30 Vdc/2A (with 2A/30V booster)
or 14 Vdc/4A (with 4A/14V booster)
or 5 Vdc/10A (with 10A/5V
booster)
225x205x410
7.5
VSP-300
[90;264]
[50; 60]
650
2 x 5 AF
260x530x510
22
VSP-300
(Vertical)
[90;264]
[50; 60]
650
2 x 5 AF
337x254x517
20
VMP-300
[90;264]
[50; 60]
1500
2 x
10 AF
533x315x563
30
HCV-3048
[85-264]
[47-440]
[1700-
2000]*
2 x
16 AF
[0;48] Vdc / ±30 A
135x400x430
26
* See power contour plot of HCV-3048
10.1.2 Environmental
- Indoor use
- Operating Temperature: 10°C to +40°C Indoor use
- Storage Temperature: 0°C to +50°C
- Pollution degree: 1 (no pollution or only dry)
- Altitude: <2000 m above sea level
- Humidity: 10% to 80% non-condensing
- Case protection: IP20
- Warm-up: 1 hour to rated accuracy
- Cooling: Internal DC Fans
- Vibration: not specified
- Choke: not specified
- Noise (audible) : <60 dBa at full power
Safety complies with EN61010-1.
EMC complies with EN61326.
RoHS complies with 2002/95/EC
10.2 Channel specifications
10.2.1 Channel board
General Functions
Potentiostat
Yes
Galvanostat
Yes
Impedance analyzer
Yes (option)
Coulometer
Yes
Linear scan generator
Yes (option)
