About the Instrument
Bio-Plex Pro and Bio-Plex Pro II Wash Stations 39
Rear Panel Connections
The instrument has the following connections on the rear panel:
Instrument Name Plate
The instrument name plate is located under the main power socket. The company
information on the top differs, depending upon where it is purchased. The nameplate
also shows the model name, the model (part) number, and the serial number.
Use the provided power cord or a similarly-rated replacement cord only.
On/Off
Main Power Socket
Inlets for Liquid Channels 1 + 2
Waste Tube
USB port
VAF
Vacuum Tubing
Ports (Bio-Plex Pro
II only)
