BioLogic BIODOM 27A - Technical Characteristics of the BIODOM 27 a Model

1. TECHNICAL CHARACTERISTICS OF THE BIODOM 27 A MODEL
Minimal Nominal
Thermal power 7.8 kW 26.9 kW
Yield 90.50 % 90.80 %
CO emissions (at 10%
2
)
33 mg/m³
Fuel Pellets C1
Boiler class (fuel) C1
Boiler class according to EN 303-5: 2012 5
Chimney connection Ø80 mm
Volume of water in the boiler 72 l
Boiler water temperature 65 °C – 80 °C
Maximum boiler water temperature 95 °C
Maximum permissible working pressure 2.5 bar
Firebox volume xxxxxxxxxxxxxx 72 l
Weight 299 kg
Power supply 220-230 V
Frequency 50 Hz
Lowest consumption of electrical energy during boiler
operation
40 W
Maximum consumption of electrical energy at boiler
ignition
300 W
Ingress Protection IP20
The boiler operates with two fans
The boiler operates according to the mode of un-
der-pressure combustion
The boiler operates without condensation conditions
Noise does not exceed 70dB
www.biodom27.si
10 BIODOM 27A
