Rev. 1.4 1.BASIC
When the battery power remains 25%, the Low Battery icon is displayed. The power is
automatically cut off after 5 minutes from the appearance of the message. The machine will no
longer operate when the “Low Battery” indication is on. Charge the batteries with the power
adaptor, which BIONET provided.
Low Battery icon :
-Battery charging time: More than 4 hours
-Continuous battery use time: Lowest 4.5 hour to highest 5 hours continuous use (buffering)
Check the electrodes of batteries before charging them.
6. Battery status indication: When battery is disconnected from equipment or out of order, it is
shown by a red `X' as shown below.
7. Low power supply: When you use the power of less than 13V, the battery indication disappears
and the ”LOW” indication is active.
Display of Low power supply
At low power (13V or less), The charge is not working.
When replacing the batteries, always remove the DC adapter and Replace.
