BM1 User’s Manual
1. General Operation
1.1 General Manu Operation
Screen Composition
10-JAN-2008 12:23
60
98
%SpO2
PR
150
50
BPM
100
90
( 93 )
120
32
RPM
EtCO2
mmHg
09:58
ADT
0:56
1HR
36.7
42.0
35.0
℃
80
30
10
20
FiCO2
0
SpO2
40mmHg
EtCO2
5
PREV
MENU
MAIN
MENU
ALARM
LEVEL
NURSE
CALL:
ON
ALL
LIMITS
ALARM
VOLUME:
OFF
ALARM
REVIEW
Real Time Wave Window：Displays measured results by up to three waves.
Menu Select Window：Menus appear when they are activated..
Parameter Window：Measured and setup data are displayed in five windows.
Parameter
Windows
Real Time Wave
Window
Menu Select Window
