Rev. 1.4 7.TEMPERATURE
96
BM1 User’s Manual
7.1 Outline
This function is used to indicate the changes of resistance generated by the changes of temperature
in numbers. The function involves the process of transferring the changes into electric signals.
Temperature Connector and Measuring Cable
Temperature Connector
SpO2
T
IPX1
IPX7
T
IPX7
Note
Temperature probe is correctly positioned and fixed to do not disconnect on the patient.
Temperature cable is attached to the monitor.
The TEMP cable connector is a high-insulation port and it is defibrillator-proof( ) .
Temperature
Measuring
Cable
